High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2

High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2

high thermal conductivity curing epoxy resin

epoxy resin with tensile strength

flexural strength epoxy resin

起源の場所:

中国上海

ブランド名:

WENYOU

モデル番号:

9219K

私達に連絡しなさい
引用を要求しなさい
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2
プロダクト細部
CAS No.:
11070-4-3
分類:
二重成分の接着剤
einecsいいえ:
216-823-5
主な原料:
エポキシ
MF:
C21H24O4
その他の名前:
エポキシ樹脂のポッティング化合物
タイプ:
エポキシ樹脂化合物
使用法:
電気断熱
キーワード:
速い治癒のエポキシの硬化剤
製品名:
トランス用エポキシAB接着剤
材料:
エポキシ樹脂+hardener
アプリケーション:
屋内使用
納期:
7日以内
パッキング:
20KG または 200KG または 1200KG
証明書:
ISO14001 19001:2015 ISO45001
アドバンテージ:
到着
成分:
ダブルコンポーネント: エポキシ + 硬化剤
混合比:
A:B=1:1
支払及び船積みの言葉
最小注文数量
1000
価格
$3.05-3.10
関連製品
よい価格 High Dielectric Strength Epoxy Resin with Thermal Stability and Chemical Corrosion Resistance for Electrical Insulation オンライン

High Dielectric Strength Epoxy Resin with Thermal Stability and Chemical Corrosion Resistance for Electrical Insulation

最もよい価格を得なさい
よい価格 Thermal Stable Low Water Absorption HB Class Curing Epoxy Resin Compound for Electrical Insulation オンライン

Thermal Stable Low Water Absorption HB Class Curing Epoxy Resin Compound for Electrical Insulation

最もよい価格を得なさい
よい価格 Hot-Curing Epoxy Resin with Viscosity 0.4-0.8 and Density 1.17-1.24 for Medium & High Voltage Transformers オンライン

Hot-Curing Epoxy Resin with Viscosity 0.4-0.8 and Density 1.17-1.24 for Medium & High Voltage Transformers

最もよい価格を得なさい
よい価格 Epoxy Resin Compound with 1:1 Mixing Ratio High Tensile Strength and Thermal Conductivity for Electrical Insulation オンライン

Epoxy Resin Compound with 1:1 Mixing Ratio High Tensile Strength and Thermal Conductivity for Electrical Insulation

最もよい価格を得なさい
私達に連絡しなさい
0086 18916511816
hope.lu@sh-wysy.com
86-21-64308192
今接触
製品の説明
Mechanical and physical properties
Properties
Value
Properties
Value
Tg（DSC）
75-95℃
Thermal conductivity
0.8-0.9W / mk
Tensile strength
65-85N/mm2
Thermal decomposition
＞320℃
Flexural strength
100-140N/ mm2
Water absorption
(23℃×10days)
0.10-0.20 % by wt.
Compressive strength
140-180N/ mm2
Water absorption (100℃×60 mins)
0.08-0.15 % by wt.
Impact strength
9-16kJ/ m2
Surface resistivity
1014Ω
Curing shrinkage
0.8-1.0%
Volume resistivity
1015Ω.cm
Flammability（4mm）
HB Class
Dielectric strength
30 kV / mm
Flammability（12mm）
HB Class
Loss factor
0.02
Detail images
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 0
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 2
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 4
Product Show
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 6
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 8
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 10
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 12
Work shop
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 14
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 16
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 18
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 20
Our factory
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 22
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 24
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 26
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 28
Packing & Delivery
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 30
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 32
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 34
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 36
Exhibition
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 38
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 40
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 42
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 44
Company profiles
High Thermal Conductivity 0.8-0.9W/mk Curing Epoxy Resin with Tensile Strength 65-85N/mm2 and Flexural Strength 100-140N/mm2 46
Our company
We are specializing in the manufacturing, R&D, and sales of epoxy resin, curing agents, and related products.
Our wide range of products includes epoxy resin, flame retardant resin, curing agents, outdoor modifiers, toughening agents, epoxy
paste, demoulding agents, and fillers.  Our high-quality products are used in high voltage electrical insulation applications and
are exported globally. We are committed to providing stable products and excellent service to the global electricity industry.
