Name: Low Viscosity Epoxy Resin with H-Class Insulation for 12-40.5kV Applications in Dry Type Transformers
Brand: Shanghai Wenyou Industry Co., Ltd.
SKU: 8316L
Price: 3.00 USD
Availability: InStock

家 > 製品 > 硬化エポキシ樹脂 >

Low Viscosity Epoxy Resin with H-Class Insulation for 12-40.5kV Applications in Dry Type Transformers

Low viscosity epoxy resin for transformers

H-class insulation epoxy resin

Dry type transformer epoxy resin

起源の場所:

中国

ブランド名:

wenyou

証明:

ISO9001, ISO14001, SGS, and UL

モデル番号:

8316L

私達に連絡しなさい

引用を要求しなさい

プロダクト細部

粘度:

3000〜7000mPa.s

密度:

1.15 - 1.19g/cm3

蒸気圧:

< 0.01Pa

納期:

約110°C

ガラス遷移温度:

60°Cから80°C

外観:

薄黄色の透明な粘性液体

支払及び船積みの言葉

最小注文数量

サンプルとして20kg/バケツ

価格

交渉可能

パッケージの詳細

20kg/バケツ,220kg/バレル,1200kg/タンク

受渡し時間

7〜10 営業日

支払条件

通常はT/T,L/C

供給の能力

十分な原材料が備わっています

Fast Curing Epoxy Resin with High Tensile Strength and Thermal Shock Resistance for Electrical Insulation

最もよい価格を得なさい

エポキシ含有量5.10-5.40、蒸気圧≦0.01の速硬化性エポキシ樹脂、高耐熱用途向け

最もよい価格を得なさい

電気隔熱高電圧トランスフォーマーでは,熱分解 > 320°Cとポットライフ 30分

最もよい価格を得なさい

熱伝導性の高いエポキシ樹脂,高強度,長持ち耐久性,CT PTの強い保温性能

最もよい価格を得なさい

私達に連絡しなさい

008618018933365

Elliot.yang@sh-wysy.com

86-21-64308192

今接触

製品の説明

Low - Viscosity Cast Resin for Dry Type Transformers: Ideal for Precise Casting

Precision is key when it comes to casting resin in dry type transformers. Our low - viscosity cast resin is the perfect choice for achieving accurate and detailed casting. The low viscosity allows the resin to flow easily into every nook and cranny of the transformer mold, ensuring complete coverage of the windings and other components. This results in a uniform and high - quality casting, free from voids and imperfections. In the manufacturing of dry type transformers with complex geometries or delicate components, the low - viscosity cast resin shines. It enables manufacturers to produce transformers with precise dimensions and excellent surface finishes. Despite its low viscosity, the resin has good mechanical and electrical properties. It hardens to form a strong and durable structure, providing reliable insulation for the dry type transformer. The low - viscosity cast resin is also compatible with a wide range of casting techniques, making it versatile for different manufacturing processes. Whether you are producing small - scale or large - scale dry type transformers, this resin can help you achieve the highest level of casting precision.

Brief Introduction

LE-8316L is a modified BPA-type epoxy resin, combined with LH-8316L, a liquid modified carboxylic anhydride hardener. This system is designed for mold forming and APG injection processes, providing high-temperature curing capabilities.

Applications

This epoxy resin is ideal for low-voltage electrical applications, including electronics, cable insulation, bonding, and sealing. It is particularly suited for sealing and connecting insulation products, as well as current and voltage transformers.

Processing Methods

Processing can be carried out using a conventional gravity casting method under vacuum conditions. The production process can also be tailored to align with the client's existing manufacturing techniques.

Properties

This two-component epoxy resin system consists of LE-8316L and LH-8316L, both in liquid form at room temperature. It is suitable for casting processes, with a glass transition temperature (Tg) ranging between 60-80°C, ensuring durability under elevated temperatures.

Formulation

Epoxy resin	LE-8316L	100 pbw
Hardener	LH-8316L	100 pbw
Filler	Silica powder	300 - 400 pbw
Color paste	LC series *	Appropriate pbw

Advantage

Low Viscosity Epoxy Resin with H-Class Insulation for 12-40.5kV Applications in Dry Type Transformers 0

Package Image

Low Viscosity Epoxy Resin with H-Class Insulation for 12-40.5kV Applications in Dry Type Transformers 1

Shipment image

Example application image

Low Viscosity Epoxy Resin with H-Class Insulation for 12-40.5kV Applications in Dry Type Transformers 3
